Connecting the
1
Cleaning Unit to
2
the Base Unit
3
Remove the cover from the cleaning unit connection socket on the rear of the base unit
Insert the connecting plug of the interconnecting hosepack into the base unit
Tighten the screws on the connecting plug of the interconnecting hosepack to secure
it in the cleaning unit connection socket
WARNING! Danger of serious injury and damage from electric shock.
If the interconnecting hosepack needs to be disconnected after commissioning
the base unit, do the following before disconnecting the hosepack:
- Disconnect the base unit power supply
- Disconnect the base unit compressed air supply
1
41
