Connecting the Cleaning Unit to the 'Robacta Ream-
er' Parting Agent Container
Connecting the
Cleaning Unit to
the 'Robacta
Reamer' Parting
1
1
Agent Container
Underside of the cleaning unit
NOTE! Only use the 'Robacta Reamer' parting agent provided by the manufac-
turer. Its composition is specifically tailored for use with the cleaning device. Cor-
rect operation is not ensured when other products are used.
1
(1)
5
6
4
Connect the parting agent hose from
2
the parting agent container to the par-
ting agent atomizer connection socket
(1) on the underside of the cleaning
unit
NOTE! The parting agent injection
time must be set via the robot con-
trol. The selected injection time
cannot be less than 0.5 seconds.
An injection time of ~ 0.7 seconds
is recommended. Depending on
the size of the gas nozzle, the nec-
essary injection time may vary.
