ProLights Chromatrix User Manual page 33

• Internal Protection: IP20
• Cooling: forced ventilation with variable-speed low-noise fans, no heat generation
• Bracket for truss rigging and hardware for connection of more units
• Vertical rig up to 16 units
• Power unit: 100-240V 50/60Hz
• IN/OUT power wiring and signal through connections XLR3p/Powercon
• Average power consumption: 315W (power output up to 6 fixtures)
• Weight: 12 kg
• Dimensions (WxHxD): 500x500x115mm
CHROMAPIX
500
Technical drawing
6°
0m
1.0m
235838 lx
3.0m
26204 lx
5.0m
9434 lx
7.0m
4813 lx
10.0m
2358 lx
Lux Center
Photometric data
115
Beam Angle: 6° Beam Width
0.10m
0.31m
0.52m
0.74m
1.05m
5
Fig.1
