- 2 - INSTALLATION

We recommend following the general guidelines below:
1. Always mount this product in a safe position and make sure there is adequate room for ventilation,
configuration and maintenance.
2. Keep any inflammable material at a safe distance from the fixture, as indicated in the safety notes.
3. Make sure that the device is not exposed to extreme heat, moisture or dust.
4. Make sure that the structure to which you are hanging the modules can support the weight.

2.1 MOUNTING

CHROMAPIX may be set up on a solid and even surface. The unit can also be mounted upside down to a
cross arm. For fixing, stable mounting clips are required. The mounting place must be of sufficient stability
and be able to support a weight of 10 times of the unit's weight.
When carrying out any installation, always comply scrupulously with all the regulations (particularly re-
garding safety) currently in force in the country in which the fixture's being used.
• Install the fixture at a suitable location by means of the mounting bracket (1).
• Always additionally secure the fixture with the safety rope from falling down. For this purpose, fasten
the safety rope at a suitable position so that the maximum fall of the fixture will be 20 cm.
• Adjust the fixture and use the knob (2) to slightly release or tighten the locking mechanism of the
bracket if is necessary.
CHROMAPIX
7
1
2
Fig.3
