Step 4 - Remove Dogging Components; Step 5 - Locate Front Activating Bracket; Step 6 - Remove Mounting Bracket - Command access MLRK1 Instructions Manual

4
If you would prefer not to have Dogging on your device, simply remove the E-Clip and the
Plastic Dogging Piece, Ball Bearing and Metal Bracket can be taken off.
E-Clip
5
Flip Pushpad Assembly over and locate the Front Activating Bracket.
Front Activating Bracket
6
Remove the E-Clip from the Pin that holds the Mounting Bracket to the Activating Bracket. Slide the
Pin out and take the Mounting Bracket off.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
installation instructions
Pushpad Assembly
Mounting Bracket
E-Clip and Pin
Activating Bracket
Metal Bracket
Ball Bearing
*Careful, these Brackets are under spring pressure.
Spring
4
Plastic Dogging
E-Clip
Mounting Bracket
Removed
Pin Removed
# 2 0 4 5 2 _ B
