Resol DeltaSol CS Plus bidirectional Manual For The Specialised Craftsman page 45

Adjustment channels
Channel Description
TCRU x* OTC runtime
TCIN x* OTC standstill interval
GFD x Grundfos Direct Sensor™
OHQM x Heat quantity measurement option
SEN x* VFD allocation
FMAX x* Maximum flow rate
MEDT x* Antifreeze type
MED% x* Antifreeze concentration (only if MEDT = propylene or ethylene glycol)
MAN1 x Manual mode R1
MAN2 x Manual mode R2
LANG x Language
UNIT x Temperature unit
RESE x Reset - back to factory settings
######## Version number
Legend:
Symbol Description
x Channel is available
x* Channel is available, if the corresponding option is activated.
Factory setting Page
30 s 61
30 min 61
OFF 61
OFF 61
2 62
6.0 l/min 62
1 63
45 % 63
Auto 64
Auto 64
dE 65
°C 65
65
45
