Adjustment channels
Channel Description
OCC2 x Collector cooling option collector 2
CMX2 x* Maximum collector temperature 2
OSYC x System cooling option
DTCO x* Switch-on temperature difference cooling
DTCF x* Switch-off temperature difference cooling
OSTC x Store cooling option
OHOL x* Holiday cooling option
THOL x* Holiday cooling temperature
OCN1 x Collector minimum limitation collector 1
CMN1 x* Minimum collector temperature 1
OCN2 x Collector minimum limitation collector 2
CMN2 x* Minimum collector temperature 2
OCF1 x Antifreeze option collector 1
CFR1 x* Antifreeze temperature collector 1
OCF2 x Antifreeze option collector 2
CFR2 x* Antifreeze temperature collector 2
OTC x Tube collector option
TCST x* OTC starting time
TCEN x* OTC ending time
TCRU x* OTC runtime
TCIN x* OTC standstill interval
GFD x Grundfos Direct Sensor™
OHQM x Heat quantity measurement option
SEN x* VFD allocation
MEDT x* Antifreeze type
MED% x* Antifreeze concentration (only if MEDT = propylene or ethylene glycol)
MAN1 x Manual mode R1
MAN2 x Manual mode R2
LANG x Language
UNIT x Temperature unit
RESE x Reset - back to factory settings
######## Version number
Legend:
Symbol Description
x Channel is available
x* Channel is available, if the corresponding option is activated.
Factory setting Page
OFF 57
110 °C [230 °F] 57
OFF 58
20.0 K [40.0 °Ra] 58
15.0 K [30.0 °Ra] 58
OFF 58
OFF 58
40 °C [110 °F] 58
OFF 59
10 °C [50 °F] 59
OFF 59
10 °C [50 °F] 59
OFF 59
4.0 °C [40.0 °F] 59
OFF 59
4.0 °C [40.0 °F] 59
OFF 60
07:00 60
19:00 61
30 s 61
30 min 61
OFF 61
OFF 61
2 62
1 63
45 % 63
Auto 64
Auto 64
dE 65
°C 65
65
