Resol DeltaSol CS Plus bidirectional Manual For The Specialised Craftsman page 13

Adjustment channels
Channel Description
OSTC x Store cooling option
OHOL x* Holiday cooling option
THOL x* Holiday cooling temperature
OCN x Collector minimum limitation option
CMN x* Collector minimum temperature
OCF x Antifreeze option
CFR x* Antifreeze temperature
OTC x Tube collector option
TCST x* OTC starting time
TCEN x* OTC ending time
TCRU x* OTC runtime
TCIN x* OTC standstill interval
GFD x Grundfos Direct Sensor™
OHQM x Heat quantity measurement option
MEDT x* Antifreeze type
MED% x* Antifreeze concentration (only if MEDT = propylene or ethylene glycol)
DT3O s Switch-on temperature difference R2
DT3F s Switch-off temperature difference R2
DT3S s Set temperature difference R2
RIS3 s Rise R2
MX3O s Switch-on threshold for maximum temperature
MX3F s Switch-off threshold for maximum temperature
MN3O s Switch-on threshold for minimum temperature
MN3F s Switch-off threshold for minimum temperature
ODB x Drainback option
tDTO x* ODB switch-on condition - time period
tFLL x* ODB filling time
tSTB x* ODB stabilisation time
MAN1 x Manual mode R1
MAN2 x Manual mode R2
LANG x Language
UNIT x Temperature unit
RESE x Reset - back to factory settings
######## Version number
Legend:
Symbol Description
x Channel is available
x* Channel is available, if the corresponding option is activated.
s System-specific channel
Factory setting Page
OFF 58
OFF 58
40 °C [110 °F] 58
OFF 59
10 °C [50 °F] 59
OFF 59
4.0 °C [40.0 °F] 59
OFF 60
07:00 60
19:00 61
30 s 61
30 min 61
OFF 61
OFF 61
1 63
45 % 63
6.0 K [12.0 °Ra] 54
4.0 K [8.0 °Ra] 54
10.0 K [20.0 °Ra] 54
2 K [4 °Ra] 55
60.0 °C [140.0 °F] 39
58.0 °C [136.0 °F] 39
5.0 °C [40.0 °F] 39
10.0 °C [50.0 °F] 39
OFF 63
60 s 64
5.0 min 64
2.0 min 64
Auto 64
Auto 64
dE 65
°C 65
65
13
