Off 60 °C [140 °F] Off - Resol DeltaSol CS Plus bidirectional Manual For The Specialised Craftsman

Display channels
Channel Description
COL x Temperature collector
TST1 x Temperature store 1 base
TST2 x Temperature store 2 base
S4 x Temperature sensor 4
TSTT x* Temperature store top
TFL x* Temperature flow sensor
TR x* Temperature return sensor
VFD x* Temperature Grundfos Direct Sensor™
L/h x* Flow rate Grundfos Direct Sensor™ / PWM feedback signal
L/h2 x* PWM feedback signal
n1 % x Speed R1
n2 % x Speed R2
h P1 x Operating hours R1
h P2 x Operating hours R2
kWh x* Heat quantity in kWh
MWh x* Heat quantity in MWh
TIME x Time
Adjustment channels
Channel Description
Arr x System
DT1O x Switch-on temperature difference R1
DT1F x Switch-off temperature difference R1
DT1S x Set temperature difference R1
RIS1 x Rise R1
PUM1 x Pump control type R1
n1MN x Minimum speed R1
n1MX x Maximum speed R1
PFB1 x* PWM feedback signal input 1
S1 MX x Maximum store temperature 1
OSEM x Store emergency shutdown option
DT2O x Switch-on temperature difference R2
DT2F x Switch-off temperature difference R2
DT2S x Set temperature difference R2
RIS2 x Rise R2
PUM2 x Pump control type R2
n2MN x Minimum speed R2
n2MX x Maximum speed R2
PFB2 x* PWM feedback signal input 2
Connection terminal Page
S1 51
S2 51
S3 51
S4 51
S4 51
S4 / VFD 51
S4 / VFD 51
VFD 51
VFD / PWM1 52
PWM2 52
R1 52
R2 52
R1 53
R2 53
- 52
- 52
- 53
Factory setting Page
6 54
6.0 K [12.0 °Ra] 54
4.0 K [8.0 °Ra] 54
10.0 K [20.0 °Ra] 54
2 K [4 °Ra] 55
PSOL 55
30 % 55
100 % 55
OFF 56
60 °C [140 °F] 54
OFF 54
6.0 K [12.0 °Ra] 54
4.0 K [8.0 °Ra] 54
10.0 K [20.0 °Ra] 54
2 K [4 °Ra] 55
PSOL 55
30 % 55
100 % 55
OFF 56
29
