Resol DeltaSol CS Plus bidirectional Manual For The Specialised Craftsman page 30

Adjustment channels
Channel Description
S2MX x Maximum store temperature 2
EM x Collector emergency temperature
OCC x Collector cooling option
CMX x* Maximum collector temperature
OSYC x System cooling option
DTCO x* Switch-on temperature difference cooling
DTCF x* Switch-off temperature difference cooling
OSTC x Store cooling option
OHOL x* Holiday cooling option
THOL x* Holiday cooling temperature
OCN x Collector minimum limitation option
CMN x* Collector minimum temperature
OCF x Antifreeze option
CFR x* Antifreeze temperature
PRIO x Priority
tLB x Loading break (store sequence control)
tRUN x Circulation time (store sequence control)
DTSE x* Spread temperature difference
OTC x Tube collector option
TCST x* OTC starting time
TCEN x* OTC ending time
TCRU x* OTC runtime
TCIN x* OTC standstill interval
GFD x Grundfos Direct Sensor™
OHQM x Heat quantity measurement option
SEN x* VFD allocation
MEDT x* Antifreeze type
MED% x* Antifreeze concentration (only if MEDT = propylene or ethylene glycol)
MAN1 x Manual mode R1
MAN2 x Manual mode R2
LANG x Language
UNIT x Temperature unit
RESE x Reset - back to factory settings
######## Version number
Legend:
Symbol Description
x Channel is available
x* Channel is available, if the corresponding option is activated.
30
Factory setting Page
60 °C [140 °F] 54
130 °C [270 °F] 55
OFF 57
110 °C [230 °F] 57
OFF 58
20.0 K [40.0 °Ra] 58
15.0 K [30.0 °Ra] 58
OFF 58
OFF 58
40 °C [110 °F] 58
OFF 59
10 °C [50 °F] 59
OFF 59
4.0 °C [40.0 °F] 59
1 59
2 min 60
15 min 60
40 K [70 °Ra] 60
OFF 60
07:00 60
19:00 61
30 s 61
30 min 61
OFF 61
OFF 61
2 62
1 63
45 % 63
Auto 64
Auto 64
dE 65
°C 65
65
