Resol DeltaSol CS Plus bidirectional Manual For The Specialised Craftsman page 19

Adjustment channels
Channel Description
OCN x Collector minimum limitation option
CMN x* Collector minimum temperature
OCF x Antifreeze option
CFR x* Antifreeze temperature
OTC x Tube collector option
TCST x* OTC starting time
TCEN x* OTC ending time
TCRU x* OTC runtime
TCIN x* OTC standstill interval
GFD x Grundfos Direct Sensor™
OHQM x Heat quantity measurement option
SEN x* VFD allocation
FMAX x* Maximum flow rate
MEDT x* Antifreeze type
MED% x* Antifreeze concentration
AH O s Switch-on temperature for thermostat
AH F s Switch-off temperature for thermostat
t1 O s Thermostat switch-on time 1
t1 F s Thermostat switch-off time 1
t2 O s Thermostat switch-on time 2
t2 F s Thermostat switch-off time 2
t3 O s Thermostat switch-on time 3
t3 F s Thermostat switch-off time 3
ODB x Drainback option
tDTO x* ODB switch-on condition - time period
tFLL x* ODB filling time
tSTB x* ODB stabilisation time
OTD s Thermal disinfection option
PDIS s* Monitoring period
DDIS s* Disinfection period
TDIS s* Disinfection temperature
SDIS s* Starting time
MAN1 x Manual mode R1
MAN2 x Manual mode R2
LANG x Language
UNIT x Temperature unit
RESE x Reset - back to factory settings
######## Version number
Legend:
Symbol Description
x Channel is available
x* Channel is available, if the corresponding option is activated.
s System-specific channel
s* System-specific channel, only available if the corresponding option is activated
Factory setting Page
OFF 59
10 °C [50 °F] 59
OFF 59
4.0 °C [40.0 °F] 59
OFF 60
07:00 60
19:00 61
30 s 61
30 min 61
OFF 61
OFF 61
2 62
6.0 l/min 62
1 63
45 % 63
40 °C [110 °F] 20
45 °C [120 °F] 20
00:00 20
00:00 20
00:00 20
00:00 20
00:00 20
00:00 20
OFF 63
60 s 64
5.0 min 64
2.0 min 64
OFF 21
01:00 21
01:00 21
60 °C [140 °F] 21
00:00 21
Auto 64
Auto 64
dE 65
°C 65
65
19
