Hp1 Operating Hours R1; Hp2 Operating Hours R2; Kwh X* Heat Quantity In Kwh; Mwh Time - Resol DeltaSol CS Plus bidirectional Manual For The Specialised Craftsman

Display channels
Channel Description
COL x Temperature collector
TSTB x Temperature store 1 base
TSTT x Temperature store 1 top
S4 x Temperature sensor 4
TFL x* Temperature flow sensor
TR x* Temperature return sensor
VFD x* Temperature Grundfos Direct Sensor™
L/h x* Flow rate Grundfos Direct Sensor™ / PWM feedback signal
n % x Speed relay
hP1 x Operating hours R1
hP2 x Operating hours R2
kWh x* Heat quantity in kWh
MWh x* Heat quantity in MWh
TIME x Time

Adjustment channels

Channel Description
Arr x System
PUM1 x Pump control type

nMN

x Minimum speed R1
nMX x Maximum speed
PFB1 x* PWM feedback signal input 1
DT1O x Switch-on temperature difference R1
DT1F x Switch-off temperature difference R1
DT1S x Set temperature difference R1
RIS1 x Rise R1
S1 MX x Maximum store temperature 1
DT2O x Switch-on temperature difference R2
DT2F x Switch-off temperature difference R2
DT2S x Set temperature difference R2
RIS2 x Rise R2
S2MX x Maximum store temperature 2
EM x Collector emergency temperature
OCC x Collector cooling option
CMX x* Maximum collector temperature
OSYC x System cooling option
DTCO x* Switch-on temperature difference cooling
DTCF x* Switch-off temperature difference cooling
R1
R1
Connection terminal Page
S1 51
S2 51
S3 51
S4 51
S1 / S4 / VFD 51
S4 / VFD 51
VFD 51
VFD / PWM1 52
R1 52
R1 53
R2 53
- 52
- 52
- 53
Factory setting Page
4 54
PSOL 55
30 % 55
100 % 55
OFF 56
6.0 K [12.0 °Ra] 54
4.0 K [8.0 °Ra] 54
10.0 K [20.0 °Ra] 54
2 K [4 °Ra] 55
60 °C [140 °F] 54
6.0 K [12.0 °Ra] 54
4.0 K [8.0 °Ra] 54
10.0 K [20.0 °Ra] 54
2 K [4 °Ra] 55
60 °C [140 °F] 54
130 °C [270 °F] 55
OFF 57
110 °C [230 °F] 57
OFF 58
20.0 K [40.0 °Ra] 58
15.0 K [30.0 °Ra] 58
