Resol DeltaSol CS Plus bidirectional Manual For The Specialised Craftsman page 44

Display channels
Channel Description
COL x Temperature collector
TST x Temperature store
S3 x Temperature sensor 3
TSTT x* Temperature store top
S4 x Temperature sensor 4
TFL x* Temperature flow sensor
TR x* Temperature return sensor
VFD x* Temperature Grundfos Direct Sensor™
L/h x* Flow rate Grundfos Direct Sensor™ / PWM feedback signal
n % x Speed relay R1
h P1 x Operating hours R1
h P2 x Operating hours R2
kWh x* Heat quantity in kWh
MWh x* Heat quantity in MWh
TIME x Time
Adjustment channels
Channel Description
Arr x System
DT O x Switch-on temperature difference R1
DT F x Switch-off temperature difference R1
DT S x Set temperature difference R1
RIS x Rise R1
PUM1 x Pump control type R1
nMN x Minimum speed R1
nMX x Maximum speed R1
PFB1 x* PWM feedback signal input 1
S MX x Maximum store temperature
OSEM x Store emergency shutdown option
EM x Collector emergency temperature
CMX s Maximum collector temperature
OCN x Collector minimum limitation option
CMN x* Collector minimum temperature
OCF x Antifreeze option
CFR x* Antifreeze temperature
OTC x Tube collector option
TCST x* OTC starting time
TCEN x* OTC ending time
44
Connection terminal Page
S1 51
S2 51
S3 51
S3 51
S4 51
S1 / S4 / VFD 51
S4 / VFD 51
VFD 51
VFD / PWM1 52
R1 52
R1 53
R2 53
- 52
- 52
- 53
Factory setting Page
10 54
6.0 K [12.0 °Ra] 54
4.0 K [8.0 °Ra] 54
10.0 K [20.0 °Ra] 54
2 K [4 °Ra] 55
PSOL 55
30 % 55
100 % 55
OFF 56
60 °C [140 °F] 54
OFF 54
130 °C [270 °F] 54
110 °C [230 °F] 57
OFF 59
10 °C [50 °F] 59
OFF 59
4.0 °C [40.0 °F] 59
OFF 60
07:00 60
19:00 61
