Multi-Picture
Multi pic Menu
Multi picture settings
Multi picture
Picture number
Multi picture mode
Active picture
Side border color
Position / Size
Position
Size
Displays content from multiple inputs.
When this option is off, a single input is displayed.
When this option is on, multiple inputs are displayed.
Select the number of pictures to display (either 2 or 4).
OTEE:
If you set [2] or [4] when using a 10-bit DisplayPort signal input, the 10-bit signal will be
decreased to 8-bit and then displayed in multi-picture. If [Multi picture] is set to [Off], a single
picture will be displayed as a 10-bit image.
Select either PiP (Picture-In-Picture) or PbP (Picture-By-Picture).
PiP:
A second input is displayed in an inset picture on the screen. The size and position of the inset
picture can be adjusted.
OTEE:
PiP is only available when [Picture number] is set to [2].
PbP:
See different inputs are viewed next to each other.
OTEE:
DisplayPort input has a limitation when picture number is set to [4].
In the selection of [DP1], [DP2], [USB-C], you can set two inputs only.
e.g. You can set [DP2], [USB-C], [HDMI1], [HDMI2]. You cannot set [DP1], [DP2], [USB-C],
[HDMI].
Selects a target picture for OSD operations.
OTEE:
Active frame is the white frame shown around the currently selected Active Picture area when the
OSD menu is open. All OSD settings you set are applied to the active picture in PiP or PbP.
Adjusts the side black bars color.
Sets the position of the Active Picture on the screen.
In PiP mode, the inset picture window can be moved in all directions. In PbP mode, the Active Picture will
only move either up or down.
OTEE:
This function is only available when [Picture number] is set to [2].
Sets the size of the Active Picture.
In PiP mode, only the inset picture [Picture2] can be adjusted. In PbP mode, as the Active Picture size
is increased the other picture will automatically decrease and vice versa when the Active Picture size is
decreased.
OTEE:
This function is only available when [Picture number] is set to [2].
English−51
