Adjusting the Luminance
1. Touch the Lumi key to open the luminance adjustment slider.
2. Touch the < or > key to raise or lower the luminance level.
3. Touch the Exit key to save the change and close the [Luminance] slider.
Touch the Reset key to discard the change.
Adjusting the Volume and Mute
1. Touch the Volume key to open the volume adjustment slider.
2. Touch the < or > key to raise or lower the volume level.
Touch the Mute key to mute or un-mute the audio.
3. Touch the Exit key to save the change and close the [Volume] slider.
Touch the Reset key to discard the change.

Power management function LED indicator patterns

The power management function is an energy saving feature that automatically reduces the power consumption of the monitor
when the keyboard or the mouse has not been used for a fixed period.
Mode
Normal operation Blue
(Maximum brightness)
Energy saving mode Amber
Dark amber
Slowly pulsating
Off mode Off

OTEE:
•
Power consumption depends on the setting of OSD or which devices are connected to the monitor.
•
This function works with computers that support VESA approved DPM (Display Power Management).
•
The LED indicator color for normal operation can be customized (see
LED indicator Power consumption
Approx. 84 W
Approx. 10 W
2 W
0.5 W
0.5 - Approx. 10 W
0.3 W
Normal operation (Backlight is on)
When meeting one of the conditions below, the monitor has passed
a certain amount of time with no video signal input.
• A computer is connected to the USB upstream port.
• [Quick recovery] is set to [On].
The monitor has passed a certain amount of time with no video
signal input when there is an active network signal input.
The monitor has passed a certain amount of time with no video
signal input and there is no network signal input.
Turn off the monitor by the
the power saving mode status.
Turn off the monitor by the main power switch.
page 53).
English−25
Mute
Condition
key. Power consumption depends on
