Using the MULTI PICTURE function

This monitor can display split screens from two sources by using any one of the input combinations shown on
NOTE: Please see MULTI PICTURE
BRIGHTNESS and SOUND INPUT settings are set to be the same for both screens.
SETUP
1. Touch MENU to open the OSD menu.
2. Select MULTI PICTURE.
In a Picture-By-Picture case, select Left
In a Picture-In-Picture case, select Main
Close the OSD menu in order to change the signal input.
3. Touch INPUT, then select the input signal used by the selected screen.
4. Return to 1 to select the input for the other screen.
In a Picture-By-Picture case, select Right
In a Picture-In-Picture case, select Sub
(page 17) and PICTURE PATTERN
as an adjustable screen.
as an adjustable screen.
then setup input signal.
then setup input signal.
English-31
(page 18).
page 17.
