Picture Menu
Picture mode
Picture mode
Preset
3D LUT Emu.
Luminance
Black
Namma
White (K)
White (x,y)
Select [Picture mode] from 1 to 10.
Sets the preset settings to use for the current [Picture mode] (see
Shows the name that you set in supported software when [3D LUT Emulation] is available.
Adjusts the overall image and screen background luminance.
When the setting is too high to display, the OSD characters are changed to yellow.
Adjusts the black luminance. When the setting is too low to display, the OSD characters are changed to
yellow.
Allows you to manually select the brightness level of grayscale.
sRNB:
Namma setting for sRNB.
L Star:
Namma setting for the CIELAB color space Lab.
Rec.1886:
Namma setting for HDTV broadcasting.
HDR-Hybrid Log:
Namma setting for HDR, typically for UHD broadcasting. System gamma can be
adjusted.
System Namma: System gamma is adjustable in 0.5-2.0 range. When [Auto] is
selected, the system gamma is automatically selected according to the [Luminance]
setting.
HDR-ST2084 (PQ): Namma setting for HDR, typically for UHD disk media and streaming videos.
Peak luminance value is adjustable.
Peak Lumi.: Sets the peak luminance value to display HDR-ST2084 (PQ) luminance
range. A larger value will improve white saturation but the picture become darker.
When [Auto] is selected, [Luminance] is used as the peak luminance setting.
DICOM:
DICOM NSDF (Nrayscale Standard Display Function) is typically used for medical
imaging.
Programmable:
A programmable gamma curve can be loaded using optional NEC software.
Custom:
Custom Value: The gamma value is selected from a range from 0.5 to 4.0 in
0.1 steps. For general images 2.2 is used. Increasing the value will make the
intermediate color darker, and lowering the value will make the intermediate color
brighter.
100
90
80
70
60
50
40
30
20
10
Adjusts the white color by temperature or x, y setting.
A lower color temperature will result in a reddish screen and a higher
color temperature in a bluish screen.
A larger x value will result in a reddish screen, a larger y value changes
the screen to greenish, and smaller x,y values will change the screen to
bluish white.
English−45
page
27).
HDR-ST2084 (PQ)
HDR-Hybrid Log
Custom
Rec.1886
L Star
DICOM
sRGB
WHITE RANGE
0.43
0.40
5000K
0.35
6500K
0.30
15000K
WHITE TEMPERATURE
0.25
0.25
0.30
0.35
0.40
x
3000K
0.45
0.48
