Using the MULTI PICTURE function

This monitor can display split screens from two sources by using any one of the input combinations shown on page 17.
NOTE: Please see MULTI PICTURE (page 17) and PICTURE PATTERN (page 17).
BRIGHTNESS and SOUND INPUT settings are set to be the same for both screens.
SETUP
1. Touch MENU to show OSD menu.
2. Select MULTI PICTURE.
In a picture by picture case, select Left
In a picture in picture case, select Main
Exit OSD in order to change signal input.
3. Touch INPUT, then select the input signal used by the selected screen.
4. Return to 1 to select the input for the other screen.
In a picture by picture case, select Right
In a picture in picture case, select Sub
as an adjustable screen.
as an adjustable screen.
then setup input signal.
then setup input signal.
English-26
