User Maintenance

3.0
3.1

Care and Cleaning of Gas Module

WARNING: Do not clean the Gas Module while it is on and/or plugged
1. The Gas Module enclosure may be cleaned with a mild soap and water solution or
CAUTION:
2. The DRYLINE
WARNING: The contents of the water trap should be handled as a
NOTE:
Gas Module 3 Operating Instructions
in.
ammoniated window cleaner. Apply cleaning solution to the cloth, not directly onto the
Gas Module. DO NOT apply large amounts of liquid. DO NOT use abrasive cleaning
agents or organic solvents.
The internal sampling system of the Gas Module does not
need to be cleaned or sterilized. There is no reverse flow
back to the patient. If the internal sampling system is
suspected to be clogged or dirty, the module should be
serviced by an authorized service person only.
™
Water Trap Assembly consists of a filter housing and reservoir that must
be checked and emptied whenever changing patients or if it is more than half full.
potential infection hazard.
Replace the complete DRYLINE
month or more often if indicated on the monitor.
• To remove the DRYLINE
its sides and pull out. An Air Leak message will be displayed. The monitor will
suspend sampling.
• Detach the reservoir from the filter housing by twisting and separating these two parts.
• Empty the reservoir and rinse with water only.
• Tightly re-attach the reservoir to the filter housing.
™
• Re-install the DRYLINE
snaps into place. Check that the Air Leak message disappears and monitoring
resumes.
0070-10-0696-02
™
Water Trap Assembly every
™
Water Trap Assembly from its receptacle, press the lugs on
Water Trap Assembly into the Gas Module, ensuring that it
3 - 1
