NOTE:
5. The message Feed Calibration Gas will appear. At this point, attach the calibration
FIGURE 2-4 Gas Calibration Menu
6. When sampling is complete, the Feed Calibration Gas message will disappear and
FIGURE 2-6 Gas Calibration Menu
Gas Module 3 Operating Instructions
If the Gas Module cannot zero, a zeroing error will be
displayed and the previous calibration data will be
restored. Repeat the calibration procedure from step 1. If
problems persist, contact Mindray DS Technical Support.
gas canister to the regulator and turn it on. Increasing gas values will appear in the
window as the Gas Module samples the calibration gas.
Adjusting will appear next to each value. An Accept menu item will also appear. If
the values are acceptable, select Accept. To cancel calibration and re-install the
previous calibration values, select Abort.
