  • Page 3 © Copyright 2013-2018 Shenzhen Mindray Bio-Medical Electronics Co., Ltd. All rights reserved. Release date: 2018-1 Revision: 7.0 Accutorr 3 Operator's Manual...
  • Page 4 Manufacturer 's Responsibility Contents of this manual are subject to changes without prior notice. All information contained in this manual is believed to be correct. Mindray is not liable for errors contained herein nor for incidental or consequential damages in connection with the furnishing, performance, or use of this manual.
  • Page 6       β...
  • Page 7    →...

  • Page 10: Table Of Contents

    7.2 Charging a Battery ..........................7-2 7.3 Replacing a Battery ..........................7-2 7.4 Battery Guidelines ..........................7-2 7.5 Battery Maintenance .......................... 7-3 7.5.1 Conditioning a Battery ......................7-3 7.5.2 Checking a Battery ......................... 7-3 7.6 Recycling a Battery ..........................7-4 Accutorr 3 Operator's Manual...
  • Page 11 A.4 Physical Specifications ........................A-2 A.5 Hardware Specifications ........................A-2 A.6 Measurement Specifications ......................A-3 B EMC ........................... B-1 C Error Codes ........................C-1 D Symbols and Abbreviations ................... D-1 D.1 Symbols ..............................D-1 D.2 Abbreviations ............................. D-2 Accutorr 3 Operator's Manual...
  • Page 12 FOR YOUR NOTES Accutorr 3 Operator's Manual...
  • Page 13   ...
  • Page 14               ...
  • Page 15 Always install or carry the equipment properly to avoid damage caused by a drop, impact, strong vibration or other mechanical force.  If you spill liquid on the equipment or accessories, contact Mindray or your service personnel.  Contact the Mindray service personnel for replacements if you find the housing is broken.
  • Page 16       ...

  • Page 17: Equipment Symbols

    The product bears CE mark indicating its conformity with the provisions of the Council Directive 93/42/EEC concerning medical devices and fulfills the essential requirements of Annex I of this directive. Note: The product complies with the Council Directive 2011/65/EU. Accutorr 3 Operator's Manual...
  • Page 18 The presence of this label indicates the machine was certified by ETL with the statement: Conforms to AAMI Std. ES 60601-1, IEC Std. 60601-1-6, IEC Std. 80601-2-30, ISO Std. 80601-2-56, ISO Std. 80601-2-61. Certified to CSA Std. C22.2 NO. 60601-1, NO. 60601-1-6, NO. 80601-2-30, NO. 80601-2-56, NO. 80601-2-61. Accutorr 3 Operator's Manual...
  • Page 20     ...
  • Page 21        ...
  • Page 22  ...
  • Page 25   ...
  • Page 27        ...
  • Page 28   ...
  • Page 29   ...
  • Page 30   ...
  • Page 31     ...
  • Page 32            ...
  • Page 33  ...
  • Page 34  ...
  • Page 37      ...

  • Page 39: Diap Communication Setup

    The PR parameter area displays “001”. Press the hardkey to toggle between 9600 bps and 19200 bps. NOTE  Refer to the DIAP Communications Protocol Service Manual (P/N 0070-00-0307) for additional information. Accutorr 3 Operator's Manual 3-13...
  • Page 41   ...
  • Page 42      ...
  • Page 43      ...
  • Page 44          ...

  • Page 45: Masimo Information

    Possession or purchase of this device does not convey any express or implied license to use the device with unauthorized replacement parts which would, alone, or in combination with this device, fall within the scope of one or more of the patents relating to this device. Accutorr 3 Operator's Manual...

  • Page 47: Monitoring Nibp

    Do not use the NIBP cuff on a limb with an intravenous infusion or arterial catheter in place. This could cause tissue damage around the catheter when the infusion is slowed or blocked during cuff inflation. Accutorr 3 Operator's Manual...

  • Page 48: Measurement Limitations

     Do not modify or replace connectors of the NIBP air hose except with mindray-approved connectors. Use neonatal and infant cuffs with CM1901 hoses only. Use pediatric/adult cuffs with CM1903 hoses only. ...
  • Page 49      ...
  • Page 50   ...
  • Page 51 Pulse rate (PR): detected pulsations per minute. PR can be obtained through SpO NIBP measurement. The PR source is SpO if SpO and NIBP are measured simultaneously. Diastolic pressure Accutorr 3 Operator's Manual...
  • Page 52 FOR YOUR NOTES Accutorr 3 Operator's Manual...
  • Page 53          ...
  • Page 54           ...
  • Page 55  ...
  • Page 56     ...
  • Page 57 ...
  • Page 59     ...

  • Page 60: Battery

    Keep the battery out of children’s reach.  Use only specified batteries.  If the battery shows signs of damage or signs of leakage, replace it immediately. Do not use a faulty battery in the monitor. Accutorr 3 Operator's Manual...

  • Page 61: Battery Maintenance

    Disconnect the monitor from the patient and stop all monitoring or measuring. Turn off the monitor. Disconnect the monitor from the AC power. Install the battery. Connect the monitor to AC power. Allow the battery to be charged uninterrupted for 6.5 hours until the battery is full. Accutorr 3 Operator's Manual...

  • Page 62: Recycling A Battery

    Note the time again. Calculate the run time by subtracting the start time from the end time. The operating time of a battery directly reflects its performance. If the operating time of a battery is noticeably shorter than that stated in the specifications, contact your Mindray service personnel. NOTE ...

  • Page 63: Care And Cleaning

    Be sure to turn off the monitor and disconnect all power cables from the outlets before cleaning the equipment. CAUTION  If you spill liquid on the equipment or accessories, contact Mindray or your service personnel.  Avoid wetting the pins and metal parts of the main unit or accessories during cleaning and disinfection.

  • Page 64: Cleaning And Disinfecting The Main Unit

    Powder *(Used as 1% Biocidal active: solution) Pentapotassium bis (peroxymonosulphate) bis (sulphate)(500g/kg), Contains dipotassium peroxodisulphate. Ⓡ Wipes Alpet D2 Surface Isopropyl Alcohol 58.6000%， Sanitizing Wipes Octyl Decyl Dimethyl Ammonium chloride 0.0075%, Dioctyl Dimethyl Ammonium Chloride 0.0030% Accutorr 3 Operator's Manual...
  • Page 65 0.125% Ⓡ n-Alkyl dimethyl ethylbenzyl ammonium PDI Super Sani-Cloth chlorides 0.25%, Germicidal Disposable Wipe n-Alkyl dimethyl benzyl ammonium chlorides 0.25%, Isopropyl Alcohol 55.0%, VIRAGUARD Hospital Isopropanol 70%,Other ingredients 30% Surface Disinfectants Accutorr 3 Operator's Manual...

  • Page 66: Cleaning The Main Unit

    8.2.3 Disinfecting the Main Unit Disinfect the equipment as required in your hospital’s servicing schedule using the disinfecting agents listed in the table above. Cleaning equipment before disinfecting is recommended. CAUTION  Never use EtO or formaldehyde for disinfection. Accutorr 3 Operator's Manual...

  • Page 67: Cleaning And Disinfecting The Accessories

    Never clean or disinfect the metalic connectors at either end of the accessories.  Use only Mindray approved cleaners and disinfectants and methods listed in this section to clean or disinfect the accessories. Warranty does not cover damage caused by unapproved substances or methods.
  • Page 68 Wipe chlorides 0.25%, Isopropyl Alcohol 55.0%, VIRAGUARD Hospital Isopropanol 70%,Other ingredients 30% Surface Disinfectants The following table lists approved Masimo SpO cable cleaning and disinfecting agents: Product Name Product Type Ingredients Isopropanol Liquid Isopropanol 70% Accutorr 3 Operator's Manual...
  • Page 69 Hydrogen Peroxide 0.5% Diversey Oxivir Wipes Ⓡ n-Alkyl dimethyl ethylbenzyl ammonium PDI Super Sani-Cloth chlorides 0.25%, Germicidal Disposable n-Alkyl dimethyl benzyl ammonium Wipe chlorides 0.25%, Isopropyl Alcohol 55.0%, VIRAGUARD Hospital Isopropanol 70%, Surface Disinfectants Other ingredients 30% Accutorr 3 Operator's Manual...

  • Page 70: Cleaning The Accessories

    Cleaning the accessories before disinfecting is recommended. 8.4 Sterilization Sterilization is not recommended for this equipment, related products, accessories, or supplies unless otherwise indicated in the Instructions for Use that accompany the products, accessories or supplies. Accutorr 3 Operator's Manual...

  • Page 71: User Maintenance

    The responsible hospital or institution should carry out all cleaning and disinfection procedure specified in this chapter.  Do not open the equipment housings. All servicing or upgrades must be carried out by Mindray trained and authorized personnel.  No modification of this equipment is allowed. ...

  • Page 72: Checking Monitor Information

    Inspect all external connections for loose connectors, bent pins or frayed cables.  Inspect all connectors on the equipment for loose connectors or bent pins.  Make sure that safety labels and data plates on the equipment are clearly legible. Accutorr 3 Operator's Manual...

  • Page 73: Power-On Test

    The work status indicator lights up inside the Power button. The screen lights up. The main interface is displayed. Now the equipment is correctly started. 9.6 Battery Check Refer to 7.5.2 Checking a Battery for battery check instructions Accutorr 3 Operator's Manual...
  • Page 74 FOR YOUR NOTES Accutorr 3 Operator's Manual...

  • Page 75: Accessories

    Adult Finger LNCS DCIP 0600-00-0127 Reusable SpO sensor Pediatric Finger LNCS NeoPt 0600-00-0156 Disposable SpO Neonate Foot sensor LNCS Neo 0600-00-0157 Disposable SpO Adult (> 40 kg) Finger sensor Neonate (< 3 kg) Foot Accutorr 3 Operator's Manual 10-1...
  • Page 76 The maximum photic output consumption of the sensor is less than 18 mW. The information about the wavelength range and maximum photic output consumption can be especially useful to clinicians (for example, when photodynamic therapy is performed). 10-2 Accutorr 3 Operator's Manual...

  • Page 77: Nibp Accessories

    24 to 35, 10 pcs/box 115-027565-00 Large Adult 33 to 47, 10 pcs/box 115-027566-00 Adult Thigh 46 to 66, 5 pcs/box 115-027567-00 Adult Long 24 to 35, 10 pcs/box 115-027568-00 Large Adult 33 to 47, 10 pcs/box 115-027569-00 Accutorr 3 Operator's Manual 10-3...

  • Page 78: Temp Accessories

    Wall Mount Bracket 045-003427-00 U.S. Power Cord 0012-25-0001 Accessories Kit Component Part No. Accutorr 3 Welch Allyn Accutorr 3 Welch Allyn Temp Support 115-022900-00 Temp Support Kit Assembly (115-025042-00) Accutorr 3 Welch Allyn Temp Support 046-006015-00 Installation Guide Li-ion Battery Kit Li-ion Battery 11.1V 4500mAh...

  • Page 79: A Product Specifications

    The equipment may not meet the performance specifications given here if stored or used outside the specified temperature and humidity ranges. NOTE  The environmental specifications of parameter modules are the same as those of the main unit. Accutorr 3 Operator's Manual...

  • Page 80: Power Supply Specifications

    134mm × 120mm × 243mm Weight ≤1.9 kg (with SpO module, NIBP module and a battery) ≤1.7 kg (with NIBP module and a battery) A.5 Hardware Specifications A.5.1 Display Screen type Segment display Screen Size 90mm × 99mm Accutorr 3 Operator's Manual...
  • Page 81 A.5.2 A.5.3 A.5.4 A.6.1 ± ± ± ±...
  • Page 82 ± ± ±...
  • Page 83 A.6.2 ± ± ± A.6.3 ...
  • Page 84  ± ± ± A.6.4...
  • Page 87        ...
  • Page 88  ± ± ± ± ± ± ± ± ± ± ± ±...
  • Page 89   ...
  • Page 90   ...
  • Page 97 µ µ µ º º...
  • Page 98 Ω Ω － – ％ ～ ＋ ＝ ＜ ＞ ≤ ≥ ± × © é é...
  • Page 102 P/N: 046-005275-00 (7.0) SW Version: 03.01.00...
