Atdec SYSTEMA SW6S Installation Instructions Manual page 6

Step 6. Cable Management (cont.)
Cable Cover
Note: Choose 6.9 and/or 6.10 for your column cable management depending on your needs.
6.9 OPTIONAL
A. Loop cable and insert into Cable Cover.
6.10 OPTIONAL (NOTE: Cable clips only come with SP40
and SP75 Posts or separately in SC4 accessory pack)
A. Push the cable down into the Cab
6.8 OPTIONAL (NOTE: The Cable Cover shown,
only comes with SP40 or SP75 posts.)
To reposition the Cable Cover, pull it straight up and
out of the post and insert it into any of the available
slots.
Cable le Clip.
6.7 Under the Channel
Clamp, pull one side of the
clip down and push the cable
through the gap.
6.9 OPTIONAL
B. Push the Cable down into either side of the Cable Cover until it reaches the bottom.
6.10 OPTIONAL
B. Insert one side of the Cable Clip into the Channel on the Post assembly or Wall
channel, before pushing the other side in.
Optional Cable Cover Positions
