Wall Full Motion Mount
COMPONENT CHECKLIST
A
Articulated
Arm Assembly
(x1)
Direct Wall Mount
Bracket Assembly
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! This mount supports a maximum weight of 3kg to 9kg (6.6lbs to 19.8lbs).
! This product supports VESA mounting hole configurations: 75x75mm and 100x100mm.
! The manufacturer accepts no responsibility for incorrect installation.
! Curved monitors, deep devices (such as all-in-one PCs) and offset VESA locations exert additional leverage that can
exceed the capacity of the mount even though the monitor weight may be within the stated range. Please contact
Atdec if you would like further information.
E
Cable Wrap
Applicator
(x1)
B
16mm Cable
Wrap
(x1)
I
M6x40
Coach Screw
(x4)
C
M
Mounting Screw
M4x16mm
(x1)
(x4)
F
G
Cable Clip
M6 Washer
Nylon
(x3)
(x4)
Archor Plugs
J
K
Extension
2.5/5mm
Top Cap
Clip
Allen Key
(x4)
(x1 each)
N
Mounting Screw
Mounting Screw
M4x12mm
M4x10mm
(x4)
Installation Guide
H
(x4)
REQUIRED TOOLS
• Phillips Head Screwdriver
L
Tool
(x1)
WEIGHT RANGE
3 - 9kg
O
6.6 - 19.8lbs
(x4)
SD-AT-DW
SD-AT-DW Page 1 of 4
