IC-KP-B6*
Communication in "IVI-B6" mode
Command: Single read read only code with head 2, without double side mode
DP master sequence
Command (B4 ... B1)
Double side (DS)
Tag type (T2, T1)
Number of words
(N4 ... N1)
Head number
(K3 ... K1)
Toggle flag (T)
Word 0 Commands and parameters
B4 B3
0 0
Table 4.1 = 1043hex
Note!
Words 1 ... 15 do not contain valid data. However, this only applies for read only
codes. In the case of read/write tags, word 1 would contain the start memory
address and words 2 ... 15 (for write commands) the data to be written.
Response from the control interface on the DP master
Singlecommands are executed once and the result (success or failure) is output.
Word 0 Word 1
1043
(hex)
or 1043
(hex)
or 1043
(hex)
Word 0: Command and parameter mirrored
Word 1: Status/execution counter/head number (see below)
Word 2 ... 5: If reading is successful, the corresponding data of the read only tag appears here.
Word 6 ... 15: No valid data
0001b
0b
00b
0100b
001b
1b
B2 B1 DS 0
0 1 0 0
Word 2 Word 3
1105 xxxx
(hex)
1106 xxxx
(hex)
1100 4235
(hex) (hex)
SF (Single read read only code)
Double side mode OFF
IDC-1k
4 words = 8 bytes (because read only code
consists of 7 bytes, the 8th byte has no meaning)
Head number 2 is addressed
(or 0, depending on the previous state after initial
command or switching on = 1)
T2 T1 N4 N3 N2
0 0 0 1 0
Word 4 Word 5
xxxx xxxx
xxxx xxxx
3433 3634
(hex) (hex)
N1 K3 K2 K1
0 0 0 1
xxxx If no read only tag in
front of head
xxxx If head not
connected or
defective.
32xx If read only tag
(hex) content "B543642"
(ASCII) in front of
head
T
1
