Below is the description for each function of the DISPLAY menu.
SDI A LVM-420A
PAGE I >> PAGE II
HD DISPLAY MODE
TIME CODE ENABLE
ORBITER CIRCUIT
CLOSED CAPTION
608 CAPTION SELECT
708 SERVICE SELECT
TELETEXT PAGE
ASPECT
SDI A LVM-420A
PAGE II >> PAGE I
SCAN
H/V DELAY
SCREEN SELECT
BORDER COLOR
BORDER THICKNESS
◦ HD DISPLAY MODE
- Controls the display ratio in HD mode.
- Available values are 16:9, 1.85:1 and 2.35:1.
TIME CODE ENABLE
◦
- This item controls the time code.
- Available modes are OFF, VITC and LTC.
ORBITER CIRCUIT
◦
- This item is available to prevent TIR on static images displayed on screen for extended periods of
time. Most scenarios do not require an orbiter circuit as TIR does not occur easily/rapidly. However,
for some Multi-Viewer type applications, this mode may be desirable. The orbiter value can be set
between 1 and 100 (number of pixels image is scaled down). The image will move onscreen every
10 minutes.
CLOSED CAPTION
◦
- This item selects Closed Caption.
- Available modes are OFF, 708, 608(LINE21), 608(ANC), OP47,OP42, OP47/42(AUTO) and 708-Kor.
* 608 : CEA-608-B, 708 : CEA-708-C standard display only.
1080/60i
16:9
VITC
OFF
OFF
CC 1
SERVICE 1
801
4:3
1080/60i
ZERO SCAN
OFF
ALL SCREEN
WHITE
1
Menu Contents
608 CAPTION SELECT
◦
- Controls Closed Caption 608.
- CC 1 ~ CC 4 supported.
◦ 708 SERVICE SELECT
- Controls Closed Caption 708 service.
- SERVICE 1 ~ SERVICE 6 supported.
TELETEXT PAGE
◦
- Controls OP47/42 pages.
- 801 ~ 8FF supported.
ASEPCT
◦
- Controls the display ratio in SD mode.
- Available modes are 4:3, 16:9, 4:3 Ex, 16:9 Ex .
SCAN
◦
- Controls th SCAN mode.
- Available modes are OVER SCAN, ZERO SCAN, UNDER SCAN, 2:1 SCAN, 1:1 SCAN, FIT WIDTH,
ZOOM(PBP 16:9 mode).
H/V DELAY
◦
- Used to check horizontal and vertical sync simultaneously by moving the screen up/down/left/
right.
- In this mode, the brightness of image automatically increase for easy verication of synchronized
signals.
SCREEN SELECT
◦
- Enables control for individual screens (1 or 2) or full screen (both) in PBP mode.
- Screen selection order : ALL SCREEN -> SCREEN 1 -> SCREEN 2.
- For easy screen selection, use [CHROMA/PHASE/SCREEN SEL] button in the front panel.
BORDER COLOR
◦
- Selects the border line color between the displays in PBP Mode.
- Available values are WHITE, GRAY, BLACK, RED, GREEN and BLUE.
BORDER THICKNESS
◦
- Adjusts border line thickness between displays in PBP Mode.
- Set value range in pixel 0 ~ 7.
