Resol BASIC controller Manual For The Specialised Craftsman page 35

c
17
STMAX
a b
PUSH
STMAX
Maximum store temperature
monitoring option
Selection: ON / OFF
Factory setting: ON
OFF
BACK
PUSH
BACK
PUSH
18
RESET 18
PUSH
17 Maximum store temperature
This function is used for detecting and indicating if the adjusted maximum store
OK
temperature has been exceeded. The controller compares the current store tem-
perature to the adjusted maximum store temperature, thus monitoring the store
loading circuits.
The maximum store temperature is considered exceeded when the temperature
measured at the store sensor exceeds the adjusted maximum store temperature by
at least 5 K. The monitoring becomes active again as soon as the store temperature
falls below the adjusted maximum store temperature.
ON
The channels ST1, ST2 can be used for selecting the stores to be monitored. The
ST1(2)
number of exceedances is displayed in the ST(2)MX channels. A possible cause for
Maximum store temperature
an unwanted exceedance of the maximum store temperature is a defective valve.
monitoring store 1, 2
Selection: ON / OFF
Factory setting: ON
ST1(2)MX
Maximum store temperature
exceedance counter
18 Reset
By means of the reset function, all adjustments can be set back to the factory
settings.
