Resol BASIC controller Manual For The Specialised Craftsman page 18

Display of store temperatures
TSTB, etc.
Store temperatures
Display range: -40 ... +260 °C
Displays the current store temperature.
• TSTB : Store temperature base
• TSTT : Store temperature top
Display of temperatures at S3
S3
Sensor temperatures
Display range: -40 ... +260 °C
Indicates the current temperature at the corresponding additional sensor
(without control function).
• S3 : Temperature sensor 3
18
Display of other temperatures
TWAMA,
etc.
Other measured temperatures
Display range: -40 ... +260 °C
Indicates the current temperature at the washing machine inlet. The display of
this temperature depends on the system selected.
• Temperature, washing machine, inlet
Display of fl ow rate
L/ , G/
Flow rate
Display range: 0 ... 9999 l/h
Indicates the currently measured fl ow rate. This value is used for calculating
the heat quantity supplied (V40).
Display of speed
1 %, 2 %
Current pump speed
Display range: 20 ... 100 % (standard pump / HE pump)
Indicates the current speed of the corresponding pump.
