Resol BASIC controller Manual For The Specialised Craftsman page 32

13
a b
BACK
PUSH
14
OK
SENS 14 SEN 1 (...4) / Sensor type
Selection: Pt1000, KTY, Pt500
PUSH (S5: Pt1000, KTY, Pt500, V40)
Factory setting: Pt1000
OFF
BACK
PUSH
15
32
c
Tcold
Cold water temperature
Adjustment range: 0 ... 20 °C
Factory setting: 10 °C
ON
VIMP / Impulse rate of the V40
Adjustment range: OFF,
0,5 ... 100,0 l/imp
Factory setting: OFF
13 Heat quantity measurement with V40 flowmeter:
The heat quantity measurement uses the difference between the flow temperature
measured at S3 and the adjusted return temperature Tcold and the flow rate
transmitted by the flowmeter.
Adjust 2 in the channel FTYPE
Note
If the flow rate detection type V40 has been adjusted, the impulse rate of the
corresponding sensor must be adjusted in the SENS menu (see page 32).
Heat quantity measurement with Grundfos Direct Sensor
The heat quantity measurement uses the difference between the flow temperature
measured at the Grundfos Direct Sensor
Tcold and the flow rate transmitted by the Grundfos Direct Sensor
Adjust 3 in the channel FTYPE
14 Sensors
The sensor type can be selected for the sensor inputs S1 to S4.
The impulse rate of the sensor connected can be adjusted for the sensor input V40.
TM :
TM
and the adjusted return temperature
TM
.
