Resol BASIC controller Manual For The Specialised Craftsman page 26

5
6
TWAMA
WAMA 6
Switch-on temperature
PUSH Adjustment range: 20 ... 90 °C
Factory setting: 40 °C
HYST
Switch-on hysteresis
Adjustment range: 0.0 ... 10 K
Factory setting: 1 K
TIMER
Timer
Adjustment range: 01:00 ... 60:00
Factory setting: 45:00
BACK
PUSH
7
26
Note
If the drainback function ODB is activated, the factory settings of the pa-
rameters DT O, DT F und DT S will be adapted to values suiting drainback
systems:
DT O = 10 K
DT F = 4 K
DT S = 15 K
Additionally, the adjustment range and the factory setting of the collector
emergency shutdown CEM will change:
Adjustment range: 80 ... 120°C; Factory setting: 95 °C
Adjustments previously made in these channels will be overridden and have
to be entered again if the drainback option is deactivated later on.
Note
If the holiday function is activated, the drainback option will not be available.
6 Washing machine water preheating
Preheating of the washing machine inlet (R2) can be carried out with a thermostat
function.
If the value at S4 reaches the switch-on temperature for the washing machine func-
tion, the function will be switched on and the temperature will be maintained at the
desired value for the adjusted time by means of the valve. After the adjusted time
has elapsed, the relay will be deactivated for the same duration.
