Indications, functions and options

Note
The values and adjustment channels as well as the adjustment ranges de-
pend on the system selected, the functions and options as well as the
system components connected to the controller.
An additional document including a list with all options and parameters
can be downloaded at www.resol.com.

8.1 Status level

Display of blocking protection time
BLSC(2, 3)
Blocking protection active
Display of drainback time periods
INIT
Initialisation active
Indicates the time adjusted in tDTO, running backwards.
FLLT
Filling time active
Indicates the time adjusted in tFLL, running backwards.
STAB
Stabilisation
Indicates the time adjusted in tSTB, running backwards.
Display of collector temperatures
TCOL
Collector temperature
Display range: -40 ... +260 °C
Displays the current collector temperature.
