4.2 Further indications

Smiley
If the controller operates faultlessly (normal operation), a smiley
Fault indication
If the controller detects a malfunction, the control LED flashes red and the symbols
of the warning triangle and the wrench
Short text and ticker
Functions, options, measurement and balance values as well as messages are in-
dicated as both short text and ticker. After the short text has been displayed, the
corresponding long text will be indicated as a ticker from right to left.
Symbol Permanently shown
Status indications:
Store maximum limitation active
(store maximum temperature has
been exceeded)
Antifreeze option activated
+
+
Holiday function active
Normal operation
Fault indication:
+
14
5
During normal operation of the controller, the display is in the status menu indicat-
is displayed. ing the values shown in the table (depending on the system selected).
In addition to the display values, possible error messages are indicated in the status
menu (see page 36).
are additionally displayed. Display
TCOL
TSTB
TSTT
TAH
S3
Flashing
n1 %
L/h
Collector cooling function active, TFHQM
system cooling or store cooling active
TRHQM
kWh
Collector temp. below minimum
MWh
temp., antifreeze function active
BLPR
Collector emergency shutdown active
BLPR2
Manual mode active
INIT
Store emergency shutdown active
FLLT
Adjustment mode
STAB
TIME
DATE
Sensor fault

Status level / Measurement values

Description (long text)
Temperature collector
Temperature store base
Temperature store top
Temperature afterheating
Temperature sensor 3
Speed relay 1
Flow rate sensor V40
Heat quantity measurement flow temperature
Heat quantity measurement return temperature
Heat quantity in kWh
Heat quantity in MWh
Blocking protection relay 1
Blocking protection relay 2
Initialisation drainback
Filling time drainback
Stabilisation drainback
