J. STEPHEN Co., Ltd.
28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea
TEL : +82-31-8077-5000 FAX : +82-31-459-8880
http://www.miniprinter.com
MOBILE PRINTER
MODEL : LK-P24
Wi-Fi & Bluetooth
P24 Rev. A 04/18
All specifications are subject to change without notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK-P24 and is the answer not in the manual?

Questions and answers

Related Manuals for SEWOO LK-P24

Summary of Contents for SEWOO LK-P24

  • Page 1 J. STEPHEN Co., Ltd. 28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea TEL : +82-31-8077-5000 FAX : +82-31-459-8880 http://www.miniprinter.com MOBILE PRINTER MODEL : LK-P24 Wi-Fi & Bluetooth P24 Rev. A 04/18 All specifications are subject to change without notice...
  • Page 3 Safety Precautions For better safety and reliability, adhere to the following precautionary measures. WARNING Read and follow the instructions carefully before operation of the product. Failure to follow these instructions could result in fire, electric shock, other injuries, or property damage. Indication Prohibition Must follow...

  • Page 4: Table Of Contents

    Table of Contents PERIPHERAL CONNECTION PRODUCT OVERVIEW 9. PERIPHERAL CONNECTION 1. UNPACKING 9-1. BLUETOOTH CONNECTION (OPTIONAL) 2. PRODUCT OVERVIEW 9-2. Wi-Fi CONNECTION (OPTIONAL) 3. AMC(ADVANCED MANUAL CUTTER) BUTTON 9-3. NFC CONNECTION (OPTIONAL) 4. CONTROL PANEL USAGE 9-4. INTERFACE CABLE CONNECTION SET UP MAINTENANCE 5.

  • Page 5: Unpacking

    2. PRODUCT OVERVIEW 1. UNPACKING Standard Front AMC Button - Button Up: Cutting the paper - Button down: Opening the cover Power Button Printer Battery Charger USB Cable Paper feed Button Roll Paper Belt Strap+Bracket Quick Manual CD (Manual) DC POWER Optional Rear Battery...

  • Page 6: Control Panel Usage

    3. AMC BUTTON 4. CONTROL PANEL USAGE (Advanced Manual Cutter) AMC function gives the convenient way for users to cut papers. Button Button Up Press the button up to cut the paper. Button Name function This button is used to turn the printer on and off. Power When the printer is off, press this button for approximately 3 seconds Button...

  • Page 7: Paper Installation

    5. PAPER INSTALLATION 6. BATTERY 6-1. Battery Installation CAUTION HOOK Make sure to be careful of the HOT head OPEN Please make sure you hear the closing sound of the upper cover. AMC BUTTON CLOSE Press the AMC button down Place the paper roll as shown.

  • Page 8: Battery Removal

    6-2. Battery Removal 6-3. Battery Charging 6-3-1. Charging Usage OPEN REMOVE LAMP 1. Remove the battery as shown. 1. Make sure the printer is turned off. 2. After opening the DC JACK cover, connect the DC JACK to the printer. 3.

  • Page 9: Charging Cradle Optional

    6-4. Set Cradle Usage 6-3-2. Charging Cradle Optional Optional 1. Place the printer into the charging cradle as shown above. Press the PUSH button to pop out 2. Connect the DC JACK to the charging cradle. the cradle connector. 3. Plug the power cord into an electrical outlet. 4.

  • Page 10: Belt Clip & Strap, Leather Case

    7. BELT CLIP & STRAP, LEATHER 7-1. Belt Strap+bracket Usage Prepare the belt strap, bracket, Put the strap into the hole on the After connecting the strap and bracket, insert the screws and 2 screws. top of the belt bracket. into the bracket hole.

  • Page 11: Belt Clip Usage Optional

    7-2. Belt Clip Usage 7-3. Leather Case Usage Optional Optional Open the leather case. Place the printer into Insert the belt clip screw into the hole of the belt clip. the leather case. Close the cover and press Connect the shoulder strap down on the Velcro.

  • Page 12: Self Test

    8. SELF TEST Self-Test Printout Sample Upon initial installation or for troubleshooting, you can run the diagnostic test to get information about : Firmware version, emulation, codepage, sensor settings, interface settings, etc. If no issues are found with the diagnostic test, examine other devices and software.

  • Page 13: Peripheral Connection

    9. PERIPHERAL CONNECTION This product can communicate with other devices via Bluetooth, 9-3. NFC Connection Optional Wi-Fi or a communication cable. 9-1. Bluetooth Connection Optional 1. The printer can be connected to devices equipped with NFC communication 1. The Printer can be connected to devices equipped with Bluetooth communication capabilities.

  • Page 14: Interface Cable Connection

    10. CLEANING THE PRINTER 9-4. Interface Cable Connection If the interior of the printer is dusty, printing quality can be reduced. In this case, follow the instructions below to clean the printer. NOTE 1. Make sure to turn the printer power off prior to cleaning. 2.

  • Page 15: Jam Error

    11. JAM ERROR 12. ROLL MEDIA SPECIFICATION CAUTION Make sure to be careful of the HOT head When you face with a paper jam Please remove the paper. error, please press the button down to open the printer cover. Core Diameter(A) 12.5mm Please make sure you hear...

  • Page 16: Black Mark

    13. BLACK MARK 14. PRINTER SPECIFICATION Printing Method Direct Thermal Printing Speed Max. 100mm/s Resolution 203 DPI Character Font A(12×24), Font B(9×17), Asian Font(KOR,JPN,CHN-GB2312,CHN-Big5), Font0/1/2/4/5/6/7, Resident TTF, Downloadable TTF, FontA~H, FontGS, Residnt TTF(Font0), Font 1~8 Barcode EAN-8,EAN8(+2+5), EAN-13, EAN13(+2+5), Codabar, Code11, Code39, Code93, Code128, ITF, LUPC- A(+2+5), UPC-E, UPC-E(+2+5), Planet, UPC-A etc 10 ~ 58...
  • Page 17 Battery Charger Input AC100~240V, 50/60Hz Output 8.4V , 800~1400mA Battery Battery type Li-ion Output 7.4V, 1510mAh Charging time 2.5 Hrs (55Hrs stand-by) Cutter AMC(Advanced Manual Cutter) 81.5×121.4×45.3 [W x D x H (mm)] Size IP43 Weight 261.5g (with battery) Temperature Operation -10~50℃...
