MOBILE PRINTER
MODEL : LK-P24
USER'S MANUAL
Aroot Co., Ltd.
28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea
TEL +82-31-8077-5000 / FAX +82-31-624-5310 / http://www.miniprinter.com
All specifications are subject to change without notice
P24 ENG Rev. 12/2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK-P24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SEWOO LK-P24

Summary of Contents for SEWOO LK-P24

  • Page 1 MOBILE PRINTER MODEL : LK-P24 USER’S MANUAL Aroot Co., Ltd. 28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea TEL +82-31-8077-5000 / FAX +82-31-624-5310 / http://www.miniprinter.com All specifications are subject to change without notice P24 ENG Rev. 12/2023...
  • Page 2 This device complies with part 15 of the FCC Rules. Risk of explosion if battery is replaced by an incorrectly type. Operation is subject to the following two conditions. Dispose of used battery according to the local disposal instructions. 1) This device may not cause harmful interference, and including  2)  T his device must accept any interference received, interference that may cause undesired operation.

  • Page 3: Table Of Contents

    Table of Contents 1. Safety Precautions 5-11. Self Test 6. Peripheral Connection 2. Unpacking 3. Product Overview 6-1. Bluetooth Connection (Optional) 6-2. Wi-Fi Connection (Optional) 4. AMC(Advanced Manual Cutter) BUTTON 6-3. NFC Connection (Optional) 5. Usage and Installation 6-4. Interface Cable Connection 5-1.

  • Page 4: Safety Precautions

    1. Safety Precautions For better safety and reliability, adhere to the following precautionary measures. WARNING Read and follow the instructions carefully before operation of the product. Failure to follow these instructions could result in fire, electric shock, Indication other injuries, or property damage. Do not disassemble, Prohibition Must follow...

  • Page 5: Unpacking

    2. Unpacking 3. Product overview Standard Front AMC Button - Button Up: Cutting the paper - Button down: Opening the cover Control Panel Printer Battery Belt Strap+Bracket Quick Manual Power Button Paper Feed Button Charger USB Cable Roll paper DC Power Optional Bottom Set Cradle...

  • Page 6: Amc(Advanced Manual Cutter) Button

    4. AMC BUTTON 5. Usage and Installation (Advanced Manual Cutter) 5-1. Control Panel Usage AMC Button AMC function gives the convenient way for users to cut papers. Button Name function - This button is used to turn the printer on and off. Button Up - When the printer is off, press this button for Power...

  • Page 7: Battery Installation

    5-2. Battery Installation 5-3. Charging Battery HOOK LAMP OPEN Please make sure  you hear the closing sound of the upper cover. CLOSE 1 Make sure the printer is turned off. 2 After opening the DC JACK cover, connect the DC JACK to the printer. 3 Plug the power cord into the electrical outlet.

  • Page 8: Charging Cradle (Optional)

    5-4. Charging Cradle 5-5. Set Cradle Usage Optional Optional Press the PUSH button to pop out the cradle connector. 1 Place the printer into the charging cradle as shown above. 2 Connect the DC JACK to the charging cradle. 3 Plug the power cord into an electrical outlet. 4 Once the charging is completed, remove the printer from the charging cradle.

  • Page 9: Battery Removal

    5-6. Battery Removal 5-7. Paper Roll Installation CAUTION Make sure to be careful of the HOT head. OPEN REMOVE AMC BUTTON Press the AMC button down to open Place the paper roll as shown. Make the paper cover. sure the paper is placed in the right direction.

  • Page 10: Belt Clip & Strap

    5-8. Belt Clip & Strap Belt Strap+Bracket Usage After connecting the strap and bracket, insert the screws into the bracket hole. Prepare the belt strap, bracket, and 2 Put the strap into the hole on the top of screws. the belt bracket. Use a screw driver to tighten the bracket.

  • Page 11: Belt Clip Usage (Optional)

    5-9. Belt clip Usage 5-10. Leather Case Usage Optional Optional Open the leather case. Place the printer into the leather case. Insert the belt clip screw into the hole of the belt clip. Close the cover and press down on the Connect the shoulder strap to leather Velcro.

  • Page 12: Self-Test Printout Sample

    5-11. Self Test Self-Test Printout Sample Upon initial installation or for troubleshooting, you can run the diagnostic test to get information about: - Firmware version, emulation, codepage, sensor settings, interface settings, etc. If no issues are found with the diagnostic test, examine other devices and software.

  • Page 13: Peripheral Connection

    6. Peripheral Connection 6-3. NFC Connection This product can communicate with other devices via Bluetooth, Wi-Fi, or a Optional communication cable. The printer can be connected to devices equipped with NFC communication capabilities. 6-1. Bluetooth Connection Optional 1 The Printer can be connected to devices equipped with Bluetooth communication capabilities (PDAs, PCs, etc.).

  • Page 14: Interface Cable Connection

    7. Cleaning the Printer 6-4. Interface Cable Connection If the interior of the printer is dusty, printing quality can be reduced.  In this case, follow the instructions below to clean the printer. NOTE 01 Make sure to turn the printer power off prior to cleaning. 02 Regarding printhead cleaning, as the printhead gets very hot during printing, turn off the printer power and wait approximately 10 minutes before cleaning.

  • Page 15: Jam Error

    8. JAM Error 9. Roll Media Specification CAUTION Make sure to be careful of the HOT head. When you face with a paper jam error, Please remove the paper. please press the button down to open Core the printer cover. Diameter (A) 12.5 mm Roll...

  • Page 16: Black Mark

    10. Black Mark 11. Printer Specification Printing Method Direct Thermal Printing Speed Max. 100mm/s Resolution 203 DPI Font A(12×24), Font B(9×17), Asian Font(KOR, JPN, CHN-GB2312, CHN- Character Big5), Font0/1/2/4/5/6/7, Resident TTF, Downloadable TTF, FontA~H, FontGS, Residnt TTF(Font0), Font 1~8 EAN-8, EAN8(+2+5), EAN-13, EAN13(+2+5), 10 ~ 58 Codabar, Code11, Code39, Code93, Code128, ITF, LUPC-A(+2+5), UPC-E, UPC-E(+2+5),...

  • Page 17: Utilities

    This program is for label form design and designed LabelMaker(CPCL) label printing. Android Utility It is a utility app that prints text, barcodes, images, (Sewoo M_Utility) etc. through Bluetooth and Wi-Fi communication,  (ESC/POS) and able to printer settings.

  • Page 18: S/W

    Mac Driver in the Mac OS environment. Android Plugin This is a print service plug-in that allows you to print (Sewoo Print Service documents, images, and web pages without installing Plugin) (ESC/POS) additional apps. This is library for communication and data output Windows SDK with Mobile printer in Windows OS.
