- Page 1 MOBILE PRINTER MODEL : LK-P30Ⅱ USER’S MANUAL Aroot Co., Ltd. 28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea TEL +82-31-8077-5000 / FAX +82-31-624-5310 / http://www.miniprinter.com All specifications are subject to change without notice P30Ⅱ ENG Rev. 02/2024...
- Page 2 This device complies with part 15 of the FCC Rules. Risk of explosion if battery is replaced by an incorrectly type. Operation is subject to the following two conditions. Dispose of used battery according to the local disposal instructions. 1) This device may not cause harmful interference, and including 2) T his device must accept any interference received, interference that may cause undesired operation.
-
Page 3: Table Of Contents
Table of Contents 1. Safety Precautions 5. Peripheral Connection 2. Unpacking 5-1. Bluetooth Connection (Optional) 3. Product Overview 5-2. Wi-Fi Connection (Optional) 5-3. Interface Cable Connection 4. Usage and Installation 6. Roll Media Specification 4-1. Control Panel Usage 7. Label Specification 4-2. -
Page 4: Safety Precautions
1. Safety Precautions For better safety and reliability, adhere to the following precautionary measures. WARNING Read and follow the instructions carefully before operation of the product. Failure to follow these instructions could result in fire, electric shock, Indication other injuries, or property damage. Do not disassemble, Prohibition Must follow... - Page 5 4 For Safety BATTERY SAFETY a. Do not disassemble battery. For better safe use, reliability and performance of the battery, b. Do not use battery when something abnormal found such as smells, deformation, please review the following instructions carefully. discoloration, and so on.
-
Page 6: Unpacking
2. Unpacking 3. Product overview Standard Front Open Button Control Panel Power Button Printer Battery Belt Clip Quick Manual Paper Feed Button Charger USB Cable Roll paper DC Power Bottom Optional Set Cradle Leather Case Shoulder Strap (Charging Cradle) SERIAL Battery Belt Clip Hole Serial Cable... -
Page 7: Usage And Installation
4. Usage and Installation 4-1. Control Panel Usage 4-2. Battery Installation Hook Button Name function - This button is used to turn the printer on and off. - When the printer is off, press this button for Power approximately 3 seconds and the printer will power on. Button When you press this button while the printer is powered on, the printer will turn off. -
Page 8: Charging Battery
4-3. Charging Battery 4-4. Charging Cradle Optional Lamp Lamp DC Jack 1 Make sure the printer is turned off. 2 After opening the DC JACK cover, connect the DC JACK to the printer. 3 Plug the power cord into the electrical outlet. 1 Place the printer into the charging cradle as shown above. -
Page 9: Car Charger Usage (Optional)
4-5. Car Charger Usage 4-6. Battery Removal Optional 180˚ Printer Rotate the belt clip as shown. Battery Cradle Connect the car charger to the printer or cradle. Input 12 ~ 24V Output 8.4V 0.8 ~ 1.2A NOTE Remove the battery as shown. Only car charger included with the printer. -
Page 10: Belt Clip Usage
4-7. Belt clip Usage 4-8. Paper Roll Installation Press the PUSH button to open the Insert the paper in the correct direction. Insert the belt clip screw into the hole of Belt clip. paper cover. See the image above. Pull a short length of paper out of the Tear off the additional paper using tear printer and close the cover. -
Page 11: Self Test
4-10. Self Test 4-9. Leather Case Usage Optional Turn off the power by pressing the While you are holding the FEED button, power button for approximately 3 press the power button. seconds. Open the leather case. Place the printer into the leather case. NOTE 01 To print ASCII pattern additionally, press the Feed button once more. -
Page 12: Msr Usage (Optional)
Self-Test Printout Sample 4-11. MSR Usage Optional Upon initial installation or for troubleshooting, you can run the diagnostic test to get information about: - Firmware version, emulation, codepage, sensor settings, interface settings, etc. If no issues are found with the diagnostic test, examine other devices and software. -
Page 13: Ic Card Usage (Optional)
5. Peripheral Connection 4-12. IC CARD Usage This product can communicate with other devices via Bluetooth, Wi-Fi, or a Optional communication cable. 5-1. Bluetooth Connection Optional 1 The Printer can be connected to devices equipped with Bluetooth communication capabilities(PDAs, PCs, etc.). Insert the card in the direction of the arrow as shown in the picture. -
Page 14: Interface Cable Connection
6. Roll Media Specification 5-3. Interface Cable Connection Serial Core Diameter (A) 12.5 mm ± 0.5 mm Roll 1 Connect USB or Serial cable to the connector on the printer. Max. Diameter (B) 56 mm NOTE Max. Media Width (C) 25 mm ~ 80 mm - Only use cables included with the printer. -
Page 15: Label Specification
7. Label Specification 8. Black Mark 10 ~ 80 10.5 14 ~ 72 (PRINT WIDTH ) 20 ~ 76 25 ~ 80 (MAX PAPER WIDTH) 14 ~ 72 (PRINT WIDTH ) 25 ~ 80 (MAX PAPER WIDTH) -
Page 16: Cleaning The Printer
9. Cleaning the Printer 10. Printer Specification If the interior of the printer is dusty, printing quality can be reduced. Printing Method Direct Thermal In this case, follow the instructions below to clean the printer. Printing Speed 100 mm/s Width 48 mm, 384 Dots/line NOTE Resolution... - Page 17 Sensor WxDxH(mm) Paper end, Black mark, Cover open, Gap 120 x 152 x 70 Size Paper type WxDxH” Thermal paper / Label 4.7 x 5.9 x 2.7 Width Weight 25 mm ~ 80 mm 530g (With Battery : 640g) Paper Thickness Environmental sealing 0.06 mm ~ 0.16 mm...
-
Page 18: Utilities
This is a print service plug-in that allows you to print It is a utility that allows you to change Windows Fonts Bitmap Font (Sewoo Print Service documents, images, and web pages without installing stored on your PC into Bitmap Fonts for use on the...
