DURADRIVE Drive Controllers
1.2
An overview of individual components of the DURADRIVE
family
Line filter for control
voltage supply unit
Control voltage supply unit
Firmware
Components shown in gray are absolutely necessary.
DOK-DURADR-HDC01.1****-PR02-EN-P
LSA Control S.L. www.lsa-control.com comercial@lsa-control.com (+34) 960 62 43 01
System voltage
NFE
NTM
DC 24 V
HDC
FWA
Fig. 1-2:
Overview of individual components
Introduction to the system
IKL - ready-made power cable
Drive controller
IKS - ready-made feedback cable
IKG - ready-made power cable
AC motor
1-3
FA5126F1.FH7
