X7, Connection For Programming Module - Rexroth Indramat DURADRIVE SYSTEM200 Project Planning Manual

DURADRIVE Drive Controllers

X7, Connection for programming module

DOK-DURADR-HDC01.1****-PR02-EN-P
LSA Control S.L. www.lsa-control.com comercial@lsa-control.com (+34) 960 62 43 01
Programming module
The programming module can be broken down into
•
Parameter module for user-specific parameters
•
Firmware modules for unit-specific firmware
Programming module
Parameter module
H1
H1
S1
S1
S3
S2
S3
S2
0
0
0
0
Fig. 4-77: X7, programming module
H1: Diagnostic display
S1: Reset key
S2,S3. Address switch
DURADRIVE HDC01.1 Drive Controller
Firmware module
4-47
Ap5146f1.fh7
