National Instruments C Series Getting Started page 22

6. (Optional) Change the name of the drive from the default name of
Overview page to a more descriptive name.
Figure 17 shows the AKD Overview page.
1
1 Software Enable/Disable
2 Command Source
3 Operation Mode
4 Clear Faults
5 Save Configuration Settings to Drive
22 | ni.com | Getting Started with NI 9514/16 Modules and AKD Servo Drives
Figure 17. AKD WorkBench Overview Page
2 3
7 8 9 10
4 5 6
6 Software Enable/Disable
7 Drive Active Indicator
8 Software Enable Status Indicator
9 Hardware Enable Status Indicator
10 Fault Indicator
on the AKD
no_name
