Polycom RealPresence RMX 1800 Hardware Manual page 26

Power Unit and Status
No. Port
1, 2 Power socket and
fan
3 Serial (RS 232)
4 USB 1
5 USB 2
6 LAN 1
7 LAN 2
8 PRI 3
9 PRI 1
10 PRI 2
11 PRI 4
For version 8.3 and higher, RealPresence Collaboration Server (RMX) 1800 supports a redundant power
unit. The two power units back up each other and are hot swappable.
Note: Get a redundant power unit
Your RealPresence Collaboration Server (RMX) 1800 is shipped with one power unit by
default. To get a redundant power unit, contact your channel sales representatives.
To insert a power unit:
1 Slide the power unit into the chassis until it snaps into place.
The system beeps because it detects a power unit inserted without a power supply connected to it.
2 Connect the unit to a power supply using the supplied power cable.
The system stops beeping.
Polycom, Inc.
Description
Built-in power socket and fan
Diagnostics only
For USB Key connection; For more information of USB Key connection, see
First Entry Power-up and Configuration in the
Server (RMX) 1500/1800/2000/4000 Getting Started Guide
For USB key connection.
For management network connection; when LAN redundancy is enabled, LAN 1
is used for both management, media and signaling network connection
For media and signaling network connection; when LAN redundancy is enabled,
LAN 2 is the backup of LAN 1 port
Note: The ISDN module with PRI ports is only available on RMX 1800 with three
DSP cards.
For ISDN network connection, PRI port can work as either an E1 or T1 port, but
not simultaneously
Indicator status of the PRI ports are as below:
• Red - ISDN network works abnormally
• Green - ISDN network works normally
• Off - ISDN PRI interface isn't enabled for any ISDN network service
RealPresence Collaboration
26
