NOTE:
FastTrak 376 permits only two drives to be used for a single Mirrored array in Auto
Setup.
You would use this method if you wish to use a drive that already contains data and/or is
the bootable system drive in your system. You will need another drive of identical or
larger storage capacity.
WARNING:
1. Backup any necessary data before proceeding. Failure to follow this accepted
PC practice could result in data loss.
2. If you wish to include your current bootable drive using the Windows NT 4.x
or Windows 2000 operating system as part of a bootable Mirrored (RAID 1)
array on your FastTrak 376, do NOT connect the hard drive to the FastTrak
376 controller yet. You MUST install the Windows NT4 or 2000 driver software
first (see page 90) to this drive while it is still attached to your existing hard
drive controller. For all other Operating Systems, proceed here.
Follow these steps:
1） Using the Spacebar, choose [Security] under the Optimize Array for section.
2） Press [Ctrl-Y] keys to save your selection. The window below will appear.
Do you want the disk image to be duplicated to another? (Yes/No)
Y - Create and Duplicate
N - Create Only
3） Press [Y] for the Create and Duplicate option. The window below will appear
asking you to select the Source drive to use. FastBuild will copy all data from the
Source drive to the Target drive.
Channel:ID
Channel:ID
Channel:ID
1 :Master
2 :Master
4） Use the arrow keys to choose which drive contains the existing data to be copied.
[Source Disk]
Drive Model
[Target Disk]
Drive Model
[Please Select A Source Disk]
Drive Model
QUANTUMCR8.4A
QUANTUMCR8.4A
[ Keys Available ]
[↑] Up [↓] [ESC] Exit [Enter] Select
Serial ATA/IDE RAID
Capacity (MB)
Capacity (MB)
Capacity (MB)
8063
8063
