Chapter 2
JP6 (Power On By USB 0/1)
A USB keyboard hot key or a USB mouse click can turn on this board. You
must also set this jumper's cap to pins 2-3 to use this function.
JP6A & JP6B (Power On By USB 2/3 and 4/5):
JP6A USB 2/3
JP6B USB 4/5
A USB keyboard hot key or a USB mouse click can turn on this board. You
must also set this jumper's cap to pins 2-3 to use this function.
22
Pin
1-2
2-3
7NJS Ultra User's Guide
Definition
Disable (default)
Enable
Pin Definition
1-2 Disable (default)
2-3 Enable
