CHAINTECH 7NJS Ultra User Manual page 105

FastBuild (tm) Utility 2.xx (c) 2002-2005 Promise Technology, Inc.
Array No
Array 2
Stripe Block: Not Available
Channel:ID
1 : Slave
11. Under [Select Drive for Rebuild], highlight the replacement drive.
12. Press [Enter] and confirm that the data will be copied on to the selected
drive. All data on the replacement drive will be written over with mirrored
information from the array drive. A progress bar will appear as below.
Please Wait While Duplicating The Image
13. Once the rebuild process is complete, the user will be asked to reboot the
system.
[ Rebuild Array Menu ]
RAID Mode
Mirror
[ Select Drive for Rebuild ]
Drive Model
QUANTUMCR8.4A
[ Keys Available ]
[↑] Up [↓] Down
Total Drv
2
[ESC] Exit [Enter] Select
Serial ATA/IDE RAID
Status
Critical
Capacity (MB)
8063
10% Complete
99
