JP25 (Setup CPU FSB Freq.):
Pin
133/166/200 MHz
1-2
2-3
This cap setups up the CPU Ext. Clock Frequency.
1-2: The default value is 133/166/200 MHz (The will allow the CPU's Ext.
Frequency and memory frequency to be adjusted through the BIOS.).
2-3: Set 100 MHz at CPU Ext. frequency. (The will allow the Memory
frequency to be adjusted through the BIOS.).
JP8 (On board Audio Enable/Disable):
Pin Definition
1-2 Enable (default)
2-3
This function allows you to enable or disable the on board audio. You must
set the jumper cap to pins 1-2 to enable or set pins 2-3 to disable this function.
Definition
(default)
100 MHz
Disable
