4

UNPACKING

The appliance is delivered in sub-assembled groups along with one set of Installation Kit and one
instruction / service manual.
Please check following at the time of unpacking
1. Mobile supporting base with castor wheels, or as ordered
2. Column, as ordered
3. Illumination Box
4. Swivel arm and Suspension arm assembly
5. Cover for swivel arm
6. X-Y motorized coupling; if ordered
7. Z-axis motorized focusing attachment with magnichanger assembly
8. Foot controls, (with Joystick in case of XY model)
9. Observation Head
10. Paired Eye Pieces; as ordered
11. Power Cord
12. Set of sterilizable caps
13. Installation Kit
a) Allen Wrench 3.00mm
b) Allen Wrench 4.00mm
c) Allen Wrench 5.00mm
d) Allen Wrench 6.00mm
e) Allen Wrench 8.00mm
f) Spanner-12/ 13mm
12. Instruction cum Operating Manual / Service Manual
Prima OPH
4
