DESCRIPTION OF PARTS

14
15
18
19
21
1. Observation Head
2. Eyepieces
3. CMO - Common Main Objective
4. Fibre Optic Cable
5. X-Y Coupling
6. Z axis coupling
7. Intensity Control Knob
8. Coupling Locking Knob
9. Up/Down Movement Control Knob
10. Cable Cover
11. Suspension Arm
12. Suspension Arm Locking Knob
5
13
12
11
17
23
10
20
9
7
8
5
2
1
14
3
15
16
18
19
21
13. Swivel Arm
14. Swivel Arm Locking Knob
15. Illumination Box
16. Lamp Changing Knob
17. On/Off switch for Foot Control
18. Connectors
19 . Pillar
20. Moveable Base
21. Castor Wheel with Lock
22. Foot Control with Joystick
23. Tension Adjustment
