- Page 1 Lx 100/200 User Manual Laboratory Microscopy Part No: 5030000-795 To ensure proper use of this instrument as well as to avoid injury while operating Issue1.0 instrument, understanding this manual completely before use is highly recommended. Printed on: July 2013...
-
Page 3: Table Of Contents
Lx 100/200 CONTENTS INTRODUCTION SAFETY INFORMATION Lx 100 Lx 200 UNPACKING YOUR MICROSCOPE Lx-100 UNPACKING YOUR MICROSCOPE Lx-200 STANDARD COMPONENTS OPTIONAL ACCESSORIES 11-12 ASSEMBLY SUMMARY OF BRIGHTFIELD OBSERVATION PROCEDURE DETAILED OBSERVATION/INSTALLATION PROCEDURE 15-19 TROUBLESHOOTING GUIDE 20-21 SPECIFICATIONS Issue 1.0 5030000-795... -
Page 5: Introduction
Lx 100/200 INTRODUCTION The Lx 100/200 are laboratory microscopes reflecting a modern design as well as the latest in optical and mechanical advancements. Designed for professionals as well as students, this microscope offers many features and functions for a diverse set of applications. -
Page 6: Safety Information
2. Do not place microscope on a flexible surface, as this could result in blocking the air vents and cause overheating/fire. 4. Always use the power cord provided by LABOMED. If the proper power cord is not used, product safety performance cannot be warranted. - Page 7 [Warning against risk of electric shock] [Warning against damage in non- compliance with instructions manual] If the warning label is stained or peeled off, contact your LABOMED distributor. Getting Ready 1. A microscope is a precision instrument with delicate glass components.
- Page 8 Lx 100/200 Caution If the microscope is used in a manner not specified by this manual, the safety of the user may not be warranted. In addition, the equipment may also suffer damage. Always use the equipment as outlined in this instruction manual.
- Page 9 Lx 100/200 Caution: Do not use aggressive organic solvent such as acetone for cleaning painted surfaces and plastic parts of the microscope. Never attempt to dismantle : Never attempt to dismantle the instrument so as to avoid the possibility of impairing its operational efficiency and accuracy.
- Page 10 Lx 100/200 Lx-100 Monocular Viewing Tube Revolving Nosepiece Objectives Mechanical Stage Abbe Condenser Coarse & Fine Focusing Knob Light Regulator On/off Switch X-Y Movement control Knob Issue 1.0 5030000-795 User Manual Lx-100/200 Printed on July,2013...
- Page 11 Lx 100/200 Lx-200 Focusable Eyepieces Binocular Viewing Tube Revolving Nosepiece Objectives Specimen Holder Mechanical Stage Abbe Condenser Coarse & Fine Focus Knob Aperture Iris Diaphragm ring Light Regulator On/Off Switch X-Y movement Control Knob Issue 1.0 5030000-795 User Manual Lx-100/200...
-
Page 12: Unpacking Your Microscope Lx-100
Lx 100/200 UNPACKING YOUR MICROSCOPE Lx-100 Mirror attachment (if ordered) Power Cord Observation tube Microscope Arm Issue 1.0 5030000-795 User Manual Lx-100/200 Printed on July,2013... -
Page 13: Unpacking Your Microscope Lx-200
Lx 100/200 UNPACKING YOUR MICROSCOPE Lx-200 Mirror attachment (if ordered) Power Cord Observation tube Microscope Arm Issue 1.0 5030000-795 User Manual Lx-100/200 Printed on July,2013... -
Page 14: Standard Components
Lx 100/200 STANDARD COMPONENTS ¡ After removing microscope from packaging, make sure that all of the following contents are present. ¡ The differences in configurations are the number of objectives, type of observation head and purchased optional accessories. ¡ The objectives have been adjusted for a tight fit to prevent any damage during transportation. To remove an objective, rotate it counterclockwise while gripping it with a rubber sheet, etc. -
Page 15: Optional Accessories
Lx 100/200 OPTIONAL ACCESSORIES System Diagram of Optional Accessories 10x EYEPIECE 15x EYEPIECE Monocular BINOCULAR WITH EYEGUARD WITH EYEGUARD Viewing body VIEWING BODY IP ACHROMAT 4x/0.10 10x/0.25 40x/0.65 100x 100x/1.25(Oil) IP SERIES OBJECTIVES BATTERY Filter ABBE CONDENSER MIRROR Issue 1.0... - Page 16 Lx 100/200 Reflection Mirror The reflection mirror is designed to be used in out door observation settings wherein a power source is not readily available. The mirror attachment makes it possible to use natural light to illuminate your specimen. The microscope should be installed in any place that is not exposed to direct sunlight.
-
Page 17: Assembly
4. Engage the fuse tray back in. Always use the designated Fuse. Using a fuse other than those specified by LABOMED may lead to a fire hazard. Caution: For Fuse replacement Set the main switch to" O" (OFF), disconnect the power cord from the wall outlet. -
Page 18: Summary Of Brightfield Observation Procedure
Lx 100/200 SUMMARY OF BRIGHTFIELD OBSERVATION PROCEDURE Flip the main switch to “ON” Place the specimen on the stage. Main switch Engage the 10X objective in the light path. Bring the specimen in focus. Adjust the observation tube and eyepieces. -
Page 19: Detailed Observation/Installation Procedure
Lx 100/200 DETAILED OBSERVATION/INSTALLATION PROCEDURE The instrument is ready for use after plugging, it does not require any physical installation. Turning the Lamp ON 1. Flip the main switch to ” ” (ON) as shown in figure 14. 2. Rotating the light intensity adjustment knob (fig. 15) increases brightness and rotating it in the opposite direction decreases brightness. - Page 20 Lx 100/200 Cover glass Cover glass This is the glass plate placed on the specimen. For optimum optical performance, the cover glass thickness, which is the distance from its surface to the specimen surface, should be 0.17 mm. Slide glass Slide glass Fig.
- Page 21 Lx 100/200 Adjusting the Interpupillary Distance The inter-pupillary distance adjustment consists of regulating the two eyepieces to align with both eyes’ pupils so that you can observe a single microscopic image through two eyepieces in stereo vision. This greatly helps to reduce fatigue and discomfort during observation.
- Page 22 Lx 100/200 Adjusting the Condenser Position and Aperture Iris Diaphragm The condenser is most often used in the highest position. If the observed field of view is not uniform enough, it may be improved by lowering the condenser slightly. Rotate the condenser height adjustment knob (1) in clockwise direction to move the condenser to the highest position.
- Page 23 Using the 100X Oil Immersion Objective The designated immersion oil should be in contact with the top lens of the 100X oil immersion objective. If not, the specimen will appear distorted and dull. It is recommended that LABOMED immersion oil is used. Immersion Process: Fig.
-
Page 24: Troubleshooting Guide
Under certain conditions, performance of the unit may be adversely affected by factors other than defects. If problems occur, please review the following list and take remedial action as needed. It you cannot solve the problem after checking the entire list, please contact Labomed for assistance. Trouble... - Page 25 Lx 100/200 Trouble Remedy Cause 9. Objective hits the specimen when The specimen is upside down Set the specimen correctly with the an objective is switched to a higher cover glass on the top magnification objective The cover glass is too thick Use a cover glass with thickness of 0.17mm...
-
Page 26: Specifications
Lx 100/200 SPECIFICATIONS 1. Illumination LED illumination system 2. Focusing mechanism Stage height adjustment mechanism Fine adjustment scale: 0.002mm per graduation Fine adjustment stroke: 0.2mm per turn Total stroke: 12.7mm Co-axial coarse and fine focusing on ball drive 3. Revolving nosepiece Quadruple positions fixed (front oriented) 4. - Page 28 CA 94538 sales@laboamerica.com LABOMED and Lx 100 & Lx 200 are registered trademarks of Labo America, Inc. With a policy of continuous development, Labo America, Inc. reserves the right to change design and specifications without prior notice. ISO 9001 : 2008...
