Note:
Shunt JP2 (labeled "INT" on the eZ80F91 Mini Enet Module sche-
matic) is unpopulated. It is connected to pin 25 of the Ethernet
PHY (KS8721) and can be used for test purposes .
Flash Loader Utility
The Flash Loader utility integrated within ZDS II allows a convenient
way to program on-chip Flash memory. Refer to Zilog Developer Studio
II—eZ80Acclaim!
UM017009-0708
eZ80F91 Modular Development Kit
®
User Manual (UM0144) for more details.
User Manual
28
eZ80F91 Module
