Figure 5. eZ80Acclaim!
Caution:
The following signals are not connected and are unavailable on
the associated pins:
–
–
–
–
–
–
–
UM017009-0708
®
MDS Adapter Board Peripheral Bus External Connector
JP1
Pin 36, DIS_FLASH
Pin 42, CS1
Pin 53, MREQ
Pin 54, IOREQ
Pin 58, INSTRD
Pin 59, BUSACK
Pin 60, BUSREQ
eZ80F91 Modular Development Kit
®
eZ80Acclaim!
MDS Adapter Board
User Manual
13
