ZiLOG eZ80F91 User Manual page 21

Figure 6. eZ80Acclaim!
Caution:
The signal on Pin 49, FLASWE, is not connected and is un-
available on the associated pin.
Table 4. eZ80Acclaim!
1
Identification
Pin # Symbol
1 - 8 PA7 to PA0 Bidirectional
11 - 18 PB7 to PB0 Bidirectional
20 - 27 PC7 to PC0 Bidirectional
28, 29 PD7, PD6
UM017009-0708
®
MDS Adapter Board I/O External Connector JP2
®
MDS Adapter Board I/O External Connector JP2
Signal Direction Active Level
n/a
n/a
n/a
Bidirectional n/a
eZ80F91 Modular Development Kit
eZ80F91 Signal
Yes
Yes
Yes
Yes
®
eZ80Acclaim! MDS Adapter Board
User Manual
17
2
