系统安装（续）
安装 mSATA 存储设备
1. 按照安装HDD步骤1&2取下HDD盖板。
2. 将MSATA金手指一端卡入卡槽，另一端下压并锁附2颗螺
丝（从机器附件盒取得）。
系统安装（续）
安装内存
1. 按照安装HDD步骤1&2取下HDD盖板。
2. 移除散热片上的6颗螺丝，取下散热片。
3. 将内存安装于内存卡槽内。
4. 从机器附件盒中取出内存散热泥和CPU散热泥，分别贴附
与内存和CPU上。
PPC-3100/3120快速入门手册 3
