English
click
The supporting device (S) can be adjusted in 18 positions. Press the pedal
release button (SF) and pull the pedestal to the fl oor. If the pedestal
L+R
stands securely on the fl oor, the stand display will be completely green.
If the indicator is red, repeat the procedure.
WARNING: The supporting device must not be suspended in the air or be
covered with any objects. Always make sure that the stand indicator is
CHECK
green.
press CHECK

4.3. Height adjustment of the headrest (A) and the harness straps (SG)

to the size of your child.

To adjust the height of the headrest (A) to the size of your child touch the
back of the headrest and pull the adjusting lever (H) up. Now you can,
depending on the size of your child, adjust the headrest (A) to it's desired
height.
29
Please check with the help of the safety indicators
on BOTH SIDES, if the seat is properly connected with
the two ISOFIX anchors (IA) of the car. Both safety
indicators must now be green.
Only a proper fi xing of BOTH ISOFIX connectors (IK)
ensures that the seat is secured properly and off ers
full protection to your child in the car!!!
Please check once more, if the child car seat is
securely fi xed onto the seat.
Only if the HEYNER® MultiFix TWIST with the
ISOFIX anchors (IA) and the supporting device (S)
are properly installed in the car the children's car
seat can achieve optimal safety for your child.
As soon you have reached the correct height, release the adjusting lever
(H) and the headrest (A) snaps into the desired height. Only a well
adjusted headrest ensures maximum safety. The headrest should be ad-
justed so that the integrated 5-point harness system (G) runs at shoulder
height of the child.
The headrest can be adjusted in 7 diff erent positions.
The harness system is adjusted with the height of the headrest.
The shoulder straps are fi rmly attached to the headrest and do not need
to be adjusted separately.
Adjust the size of the harness system (G) to your child by adjusting the headrest (A).
The headrest must be adjusted so that the distance between the shoulders
of the child and the headrest does not exceed 3 cm (about 2 fi nger widths).

4.4. Fastening your child's seatbelt

Make sure that the headrest is locked in place before seating your child.
Loosen the shoulder straps by pressing the belt adjuster (GV) and pull the
harness straps (G2) towards you.
Attention:
Do not pull on the shoulder pads.
Open the seat belt buckle (D) and the belt system (G).
Place the harness straps (G2) to the left and to the right side. Now place the
child into the seat of the HEYNER® MultiFix TWIST so that the buttocks
press deeply into seat.
Insert the two buckle tongues (C) of the harness strap (G2)
and connect it to the belt buckle (D) until you hear a clear „click" sound.
By pulling on the central adjusting belt (G5) make
sure that the harness belts touch the child fi rmly and are not twisted.
English
Press
30
